C03 – Structural Analysis
A practical introduction to finite element fundamentals and ANSYS-based structural modeling for offshore structural engineering learners. The course develops engineering judgment for verifying, interpreting, and comparing linear-elastic FEM results across truss, beam, plane-stress, and simplified pressure-vessel problems.
£299.00
20 hours
Focused, self-paced learning designed to fit around professional schedules.
Online, self-paced
Study online at a pace that fits your schedule.
9 sections
Structured curriculum sections.
English
Language of instruction for this course.
1 lessons
Focused lessons organised into a clear learning path.
Course overview
A practical introduction to finite element fundamentals and ANSYS-based structural modeling for offshore structural engineering learners. The course develops engineering judgment for verifying, interpreting, and comparing linear-elastic FEM results across truss, beam, plane-stress, and simplified pressure-vessel problems.
What you will learn
Explain how finite element models represent linear-elastic static structures and where their assumptions apply.
Select suitable line, beam, and solid idealizations for common structural-analysis problems.
Perform and interpret basic ANSYS workflows for cantilever-beam, truss, plane-stress, and pressure-vessel models.
Verify FEM output using hand checks, assumptions, and sensitivity comparisons.
Evaluate alternative model results and justify conclusions using engineering judgment.
Skills and knowledge
FEM fundamentals
ANSYS
Beam analysis
Truss modeling
Plane stress
Thermal loading
Pressure vessels
Result verification
Course curriculum
Introduction
1.1 Welcome
FEM Foundations
Modeling Choices
Beam Analysis in ANSYS
Truss Jacking System
Thermal Plane Stress
Pressure Vessel Models
Worked Case Study
Summary
Ready to enrol?
£299.00
